2 Ethernet Port 4 SFP Fiber 1000M optilink media converter 20KM

Features:

1. Commonly applied in network series or cascade occasions, with 1000M uplink fiber port and downlink fiber port
2. stand-alone Type
3. Using WDM wavelength 1310nm and 1550nm to achieve single fiber bi-directional transmission
4. Broadcast filtering feature/Address auto learning/ Automatic update feature/Store and forward operating mechanism
5. Cache is 512KB, MAC address table is 4KB
6. Ethernet 10Base-T or 100Base-Tx to 100Base-Fx, or 1000Base-T to 1000Base-LX/SX fiber media converter
7. Support IEEE 802.3u, IEEE 802.3x, IEEE 802.3z/AB, IEEE 802.1d
8. Supports full-duplex or half-duplex backpressure flow control work, and with auto-negotiation capability
9. TP port supports 1000Mbps, 100Mbps, 10Mbps, two TP port could match different rate (When full-duplex bandwidth up to 2*Mbps)
10. Provide remote link loss diagnostics, TP port and FX port link connection diagnostic, dynamic data transmission, full / half duplex, rate indicator
11. Provide 4 RJ-45 port , and support automatically cross-recognition, connected with switch, set line
12. FX port with good feature, strong compatibility and high reliability, can be well compatible with Cisco, Nortel, 3COM etc
13. Excellent after-sales service, providing three years quality assurance and life-long maintenance services

General Parameter:

Shenzhen Handar Optical Technology Co.,LTD,Located in shenzhen,china,was founded in 2009,which is professionally engaging in researching & developing,manufacturing,and marketing fiber optical communication product.

With several-year development,Handar has established a profession teechinical team,strict quality control system and hight -tech production line.

Currenty Handar featured product including SFP transceiver 155M/1.25G/10G/40G/100G,media converter,AHD/TVI/CVI video to fiber converter and industrial ethernet switch. They are widely adopted in IP LAN,WAN, Telecommunicaton and hight definition CCTV systems.Users include China Telecom,China Unicom,China Mobile,China Broadcast&Television,also we are exported to more than 30 countries and areas,such as USA,Germany,Spain,Russia,Denmark,Korea ,Malaysia,Singapore and etc.

Handar is aimed at establish long term relationship with global partners,we providing better quality,effective price,excellent after-sales-sevices.We are ISO 9001 certificated company,our products got CE certificate and were approred by RoHS standard.
