    2 Port Gigabit Outdoor Ethernet Switch , Industrial Fiber Optic Network Switch

    Ask Lasest Price
    Brand Name : HD
    Model Number : HD-2224-SFP
    Certification : CE/RoHs/FCC
    Price : negotiation
    Payment Terms : T/T or western Union
    Supply Ability : 50000 pcs per month
    Delivery Time : 3-7working days after received deposit
    • Product Details
    • Company Profile

    2 Port Gigabit Outdoor Ethernet Switch , Industrial Fiber Optic Network Switch

    gigabit outdoor network switch 2 port sfp 4 port ethernet mini industrial fiber optic equipment switch


    Feature:

    1. Two SFP socket and four rj45 port
    2. Converts optical/electrical Ethernet signals between 10/100/1000M UTP ports and 1000M optical fiber ports
    3. Auto negotiation function supports UTP ports to auto 10/100/1000M and Full duplex/Half Duplex
    4. Broadcast storm protection
    5. Supports VLAN and QoS
    6. 1536 byte maximum frame
    7. Low power consumption, low heat
    8. High Performance

    Technical Specifications


    Operating StandardsIEEE802.3z/AB, 10/100/1000Base-T and 1000Base-SX/LX
    MAC Address1K
    Frame Buffer Memory512 kb RAM
    Bandwidth12 G, can be transmitted to achieve non-blocking wire-speed
    UTP CableCat. 5 (up to 100 m)
    Multimode Fiber50/125, 62.5/125 μm (up to 224/550 m)
    Single Mode Fiber8/125, 8.7/125, 9/125, 10/125 μm (up to 100 km)
    Flow Control Full DuplexIEEE802.3x flow control; Half Duplex: back pressure flow control
    PowerAC 100 to 240 V, 50 to 60Hz; DC 5V 2A
    Environment temperature0 °C to 50 °C
    Storage temperature-20°C to 70°C
    Humidity

    5% to 90%


    Interface


    RJ45 port
    10/100/1000BaseT(X) speed Auto-Negotiation, Full/Half Duplex mode, MDI/MDI-X connection
    SFP port
    1000M SFP ports (1000Base-X, 1000Base-T optional), max distance to 120km

    Switch Characteristics


    10Base Switching Speed
    14881pps
    100Base Switching Speed
    148810pps
    Transmission Mode
    Store-and-forward switching
    Cache Size
    1Mbits
    MAC Address Table
    1K
    Switching Bandwidth
    12Gbps

    Power Requirements


    Input
    Wide DC power input (12V/24V/48V) with 7.62mm industrial power terminal
    Full-load Consumption
    < 4.8W (@24VDC)

    Physical Characteristics


    Dimensions
    40mmx128mmx102mm( L x W x H )
    Weight
    300 g
    Housing
    Metal, IP40 protection
    Installation
    Wall mounting or DIN rail mounting

    Environment Limits
    Work Temp
    -40℃~85℃
    Storage Temp
    -40℃~85℃
    Relative Humidity
    5%~95% (non-condensing )

    gigabit outdoor network switch 2 port sfp 4 port ethernet mini industrial fiber optic equipment switch
