Optical BIDI 10G SFP Transceiver 1.5 Watt With 1330nm/1270nm Wavelength

Ask Lasest Price
Brand Name :	HD
Model Number :	HD-SFP+/10G-BIDI-80A/B
Certification :	CE/RoHs/FCC
Price :	negotiation
Payment Terms :	T/T, Western Union
Supply Ability :	50000 pcs per month
Delivery Time :	3-7working days after received deposit

Add to Cart

Product Details
Company Profile

Optical BIDI 10G SFP Transceiver 1.5 Watt With 1330nm/1270nm Wavelength

10G BIDI SFP+ TX1330nm/RX1270 20km optical transceiver WDM SFP

Description:

The AscentOptics 10GBASE SFP+ BIDI modules Complaint with IEEE 802.3ae 10GBASE-LR,Electrical interface compliant to SFF-8431 specifications for enhanced 8.5 and 10 Gigabit small form factor pluggable module “SFP+”,1270/1330nm DFB transmitter, PIN photo-detector,Simplex LC connector,2-wire interface for management specifications compliant with SFF 8472 digital diagnostic, Compliant with SFF8472 Digital Diagnostic Standard,ROHS compliant

Features

Optical interface compliant to IEEE 802.3ae 10GBASE-SR
Electrical interface compliant to SFF-8431
Hot Pluggable
850nm VCSEL transmitter, PIN photo-detector
Maximum link length of 300m on 2000MHz/km MM
Very low jitter
Operating case temperature: 0 to 70°C
Low power consumption
All-metal housing for superior EMI performance
Advanced firmware allow customer system encryption information to be stored in transceiver
Cost effective SFP+ solution, enables higher port densities and greater bandwidth

Parameter

Brand	HD
P/N	HD-SFP+/10G-BIDI-80A/B
Form Factor	XFP
Wavelength	1270-1610nm
Distance	80KM
Data Rate	10Gb/s
Connector	LC
Power Supply	3.3V
Maximum Power Consumption	1.5W
Operating Temperature	0°C to 70°C
DDM / DOM	YES
Warranty	1 year
Certification	CE / FCC / RoHS / TUV / UL
Compatible With	Cisco / Huawei / HP / ZTE / H3C / Juniper etc

Application

Data Center Interconnect
CPRI/OBASI Wireless Backhaul
LTE eNode B Interconnect

Order information

HD-SFP+/10G-BIDI-10A	10G	1270nm/1330nm	10KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-10B	10G	1330nm/1270nm	10KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-15A	10G	1270nm/1330nm	15KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-15B	10G	1330nm/1270nm	15KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-20A	10G	1270nm/1330nm	20KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-20B	10G	1330nm/1270nm	20KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-40A	10G	1270nm/1330nm	40KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-40B	10G	1330nm/1270nm	40KM	SM	LC	3.3V	DFB+PIN
HD-SFP+/10G-BIDI-60A	10G	1270nm/1330nm	60KM	SM	LC	3.3V	DFB+APD
HD-SFP+/10G-BIDI-60B	10G	1330nm/1270nm	60KM	SM	LC	3.3V	DFB+APD
HD-SFP+/10G-BIDI-80A	10G	1490nm/1570nm	80KM	SM	LC	3.3V	EML DFB+PIN
HD-SFP+/10G-BIDI-80B	10G	1570nm/1490nm	80KM	SM	LC	3.3V	EML DFB+PIN

FAQ

Q:Are you a factory or trading company?
We are a factory

Q:What’s the most valuable and important parts for fiber optical converter ?
Chipset, fiber transceiver and power adaptor
Q:How does Ho-link make the quality control of media converter/SFP transceiver/video converter ?
Every product must be tested as above process before leaving factory.
Q:How about the Handar product price ?
Handar can not make sure our price is the lowest in the market, but we can make sure our price is the most competitive based on the same quality.
Q:What’s MOQ for OEM ?
There is no quantity limit.
Q: How long can you prepare the samples?
Samples can be prepared within 3 days after receiving the payment.
Q: What's the trading term and payment method?
The trading term we prefer is EXW, if you require different term, contact to discuss it. And the payment method we prefer is T/T, but we can still accept the payment western union.
Q: What's the guarantee for the product?
We provide 36 months guarantee of repairing.
Q :Do you ship internationally?

10G BIDI SFP+ TX1330nm/RX1270 20km optical transceiver WDM SFP
