1 fiber +1 rj45 port 10 100mbps inner card of fiber ethernet media converter

Over View

The Ethernet media converters are designed to transmit and receive 10/100Mbps data over multimode or single mode optical fiber. The electrical interface will Auto-Negotiate to a 10Mbps, or 100Mbps Ethernet rate without any adjustments. The optical interface operates at a 100Mbps Ethernet rate. LED indicators are provided for rapidly ascertaining equipment operating status.

Key Features

1. Plug and play, high performance, Low power consumption

2. Complies with IEEE802.3 (10BASE-T) and IEEE802.3u (100BASE-TX/FX) standards

3. Electrical port supports Auto-Negotiation for 10Mbps or 100Mbps, full duplex or half duplex data.

4. Automatic MDI/MDI-X crossover

5. Distances up to: 2 km Multimode, 25-120 km Single Mode

6. ST, SC, FC LC optical connectors

7. AC/DC powered

8. Status LED's for TX,FX LINK/ACT, POWER,100M to easily monitor network status
